The Monster

Schematic by Jean Hiraga published in "L'Audiophile". It was not named "The Monster" because of its power (8W) but because its power supply, completely oversized ...

Amplifier

Component Insertion

Power Supply 1

The original power supply.

Power Supply 2

Another power supply.
